Compatible Vehicles:
VW Touareg 2003 2004 2005 2006 2007 2008 2009 2010
Note above year range is for your reference only. Send a photo of your vehicle's dashboard(radio system) to info@carnaviplayer.com to verify your fitness if you are unsure about fitness.
Attention:
1. This product is compatible with VW Touareg 2003-2010 with based radio, RNS 510, and MFD RNS 2 DVD head unit.
2. If the car has MFD RNS 2 radio, select the "Extension cable" from the above add-ons box. We will include six meters long speaker wires to bypass the digital amplifier, and there will be only four-door speakers working. Please acknowledge.
3. Steering wheel control buttons(or only vol+/- buttons work) may not work due to your car equips with a 1.6 CANBUS system(there is no way to check what CANBUS version it is on your vehicle); please kindly know this before place the order!
4. The factory backup camera will not work with our radio. Please buy our aftermarket backup camera for Touareg instead.
If you are still unsure about the radio system on your vehicle, please send a photo of the dashboard(radio system) to our email info@carnaviplayer.com. We will check and advise!
Installation photo
Installation Guide: http://www.carnaviplayer.com/docs/Installation_instructions/VW_Touareg_2003-2010_Radio_installation_manual.pdf
FAQ: This head unit is plugged and play. It has the same plug and harness as the original radio. But you guys may still have some questions refer to installation.
1. Why the radio reception is terrible?
Answer: You need to power the radio booster to make it work. The radio booster adapter is sold separately: Fakra(Z) to DIN(m) with Booster radio antenna adapter.
2. Where should I mount the GPS antenna?
Answer: You can mount the GPS antenna on the dashboard's middle or right top corner.
3. Where should I mount the external Microphone?
Answer: Our radio has an internal microphone. Usually, you do not need to install the external Microphone. But you can buy an external microphone if you think the internal Microphone's sound quality is not good. For example, you can mount the external Microphone on the A-pillar and near your head to get good voice call quality.
4. How can I install the backup Camera?
Answer: Please check this link: Touareg Backup camera
5. There is not enough room for the harness, which causes the radio to pop up on the dashboard.
Answer: Please cut the plastic parts as shown below photo. Then there will be enough room behind the radio allows you to clear up the harness. These plastic are unused, and you can restore the factory radio after cutting them.
6. Where should I mount the USB cables?
You can mount the cables in the middle or passenger storage box.
Powerful Performance. Built for Your Drive.
Advanced hardware delivers smooth multitasking, faster response and plenty of storage for your in-car entertainment experience.
Powerful CPU
High-performance processing power for faster response and smooth operation.
High-Speed RAM
Enjoy smoother multitasking and seamless switching between applications.
Ample Storage
Plenty of space for your favorite apps, music, videos and navigation data.
Upgrade Your In-Car Experience
Transform your driving experience with premium multimedia entertainment, online music streaming, and real-time navigation. Enjoy a smarter, more connected, and more enjoyable journey every time you get behind the wheel.
Seamless Integration & Touchscreen Control
Designed to integrate with your vehicle's original system, this upgrade features factory-compatible wiring and connectors for a clean installation. Retain your original audio system and steering wheel controls while enjoying the convenience of touchscreen operation.
Wireless Smartphone Connectivity
Connect your smartphone via Bluetooth and Wi-Fi for convenient access to compatible smartphone features. Use navigation, make hands-free calls, and stream your favorite music while keeping your phone safely in your pocket. The included GPS antenna helps provide accurate navigation positioning.
Apple CarPlay
Bring your favorite iPhone features to your car's display. Use Siri voice control or the touchscreen to access navigation, music, phone calls, and messages while keeping your attention on the road.
- Siri voice control
- Navigation and music access
- Calls and messages on the go
Android Auto
Stay connected with Android Auto. Use voice commands to send messages, make phone calls, navigate with Google Maps, and control your music without taking your hands off the wheel.
- Google Assistant voice commands
- Google Maps navigation
- Convenient music and call control
Wireless connection availability depends on your smartphone, country, or region.
Bluetooth Music & Hands-Free Calling
Enjoy convenient wireless audio streaming and hands-free calling through your car's sound system. Connect your smartphone via Bluetooth and enjoy your favorite music and calls while driving.
- Wireless music streaming
- Hands-free phone calls
- Convenient Bluetooth connection
Powerful & Faster CPU
Powered by a high-performance processor, the system delivers responsive operation and smooth multitasking for your everyday driving needs.
- Faster system response
- Smoother multitasking
- Enjoy a more fluid user experience
Easy Installation, Plug & Play
Designed for straightforward installation with the supplied cables and connectors. No cutting of factory wiring is required. Professional installation is recommended to ensure proper connections and the best results.
- Vehicle-specific wiring harness
- Supplied installation accessories
- No factory wire cutting required
FM/AM Radio
Enjoy your favorite local FM and AM radio stations with convenient station tuning. Stay entertained and informed with music, news, and traffic updates during your journey.
USB Music & Video Playback
Connect a USB flash drive to the supplied USB port and enjoy your favorite digital media directly through the radio.
- USB music playback
- USB video playback
- Convenient access to stored media
Equalizer Settings
Fine-tune your in-car audio to match your personal listening preferences. Adjust bass, treble, and other sound frequencies to create an audio experience that suits you.
- Adjustable bass and treble
- Customizable sound settings
- Personalized listening experience
Network Connectivity
Stay connected on the road with Wi-Fi connectivity. Access online navigation, music streaming, and other internet-based services.
- Wi-Fi connectivity
- Access to online services
Backup Camera (Optional)
Make reversing and parking easier with an optional backup camera. The display automatically switches to the rear camera view when reverse gear is engaged.
- Automatic reverse display
- Clear night vision
- Improved rear visibility
Front In-Dash Camera (Optional)
Add an optional front camera to record video while driving. Enjoy convenient touchscreen control and a straightforward plug-and-play connection.
- Forward-facing video recording
- Touchscreen control
- Optional camera accessory
OBD Diagnostic Adapter (Optional)
Connect an optional OBD adapter to monitor supported vehicle data and read engine fault codes. Available information and functions depend on your vehicle model and OBD system.
- Vehicle data monitoring
- Engine fault code reading
- Vehicle compatibility dependent
DAB+ Digital Radio Tuner (Optional)
Upgrade your radio with an optional DAB+ tuner to enjoy digital radio broadcasts and access available digital stations with clear reception.
- Digital radio reception
- Access to available DAB+ stations
- Subject to local DAB+ coverage
